High quality and factory price
·Simple on-site processing;
·Mating safety provided by keyed housings;
·Mutiple plugging and unplugging cycles;
·Accomodates PV cable with deferent insulation diamaters;
·High current carrying capacity;
. Rated current:up to 30A
Solar energy system
|
Item |
SOLAR CONNECTOR |
|
Model Number |
WSPVCC |
|
Test Voltage |
1000V DC |
|
Overvoltage Type/Pollution Degree |
6000V(50Hz, 1min) |
|
Contact Resistance Of Plug Connector |
CAT III /2 |
|
Contact Resistance Of Plug Connector |
ImΩ |
|
Contact Material |
Copper, Tin-plated |
|
Insulation Material |
PPO |
|
Degree Of Protection |
IP2X/IP67 |
|
Flame Class |
UL94-VO |
|
Safety Class |
II |
|
Suitable Cable |
OD 4.5-8.5(2.5-6.0mm2) |
|
Insertion Force/Withdrawal Force |
≤ 50N/ ≥ 50N |
|
Connecting System |
Crimp connection |
|
Temperature Range |
-40℃ ~ +125℃ |
